KEQINX 4K 1×8 HDMI Extender Splitter 70m/230ft HDMI Over Ethernet Splitter POC Satellite TV Splitters

• ✔ 1×8 HDMI Extender Splitter: 1x HDMI in 8x CAT out and 8x Receivers with POC EDID IR LOOP out.
• ✔ POC: Splitter Powering 8 Receivers, only need 1 power supply.
• ✔ Audio: Support audio formats: LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio
• ✔ Design: Compact design for easy and flexible installation, with 2x Mounting ears and 8 × Machine Screw (KM3*4).
• ✔ Distance: Support 70m/230ft under 1080P resolution and 40m/131ft under 4K@30hz resolution.
• ✔ Dimensions: Transmitter: 295mm (W) × 82mm (D) × 18mm (H) Receiver: 79.5mm (W) × 69mm (D) × 16.5mm (H)

---

Product Description

4K high resolution

Support Video resolution :

480i ~1080p50/60Hz, 4Kx2K@30Hz (4：4：4)

Audio Formats

LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio.

POC Function

Power Over CAT cable，Splitter Powering 4 Receivers,only need 1x Power Supply

1×8 HDMI splitter 4K 70m with 8 receivers

HDMI Compliance	HDMI 1.4, HDCP 1.4
Video Bandwidth	297MHz/10.2Gbps
Video Resolution	480i ~1080p50/60Hz, 4Kx2K@30Hz (4：4：4)
Color Depth	8-bit,10-bit,12-bit (1080p@60Hz); 8-bit (4K30Hz)

Color Space	LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio
Dimensions	Transmitter: 210mm (W) × 83mm (D) × 18mm (H) Receiver: 79.5mm (W) × 69mm (D) × 16.5mm (H)
Transmission Distance	1080P@60–70M/230ft, 4K30 –40M/131ft over CAT6
POC	12V POC, RX no need power supply

Package Contents

1 × HDMI 1×8 Splitter

8 × CAT Receiver

1 × IR Blaster Cable (1.5 meters)

8 × IR Receiver Cable (1.5 meters)

2 × Mounting Ear

1 × 12V/2.5A DC Locking Power Adapter

8 × Machine Screw (KM3*4)

1 × User Manual
