1400W Solar Grid Tie Inverter Mppt Pure Sine Wave

1400W Solar Grid Tie Inverter Mppt Pure Sine Wave 110V/80-160VAC Output Mirco Inverter Automatic Identification Power Inverters

1400W Solar Grid Tie Inverter Mppt Pure Sine Wave 110V/80-160VAC Output Mirco Inverter Automatic Identification Power Inverters, for 30V Or 36V Solar Panels

  • 【HIGH-QUALITY MATERIAL】The grid tie inverter is made of aluminum alloy, which is rust-free, heat-resistant, cold-resistant. It also uses imported industrial electronic components, which you can use for a long time.This grid tie inverter converts the direct current generated by the solar panel into alternating current
  • 【HIGH EFFICIENCY】This grid tie inverter adopts a unique circuit design, imported industrial electronic components, isolated high-frequency transformer, and unique MPPT technology, with efficiency greater than 99%, so it can achieve sensitive response and more stable maximum power point locking. It can better protect sensitive devices, provide stronger driving ability, and lower power consumption.
  • 【DIGITAL CONTROL】The inverter adopts intelligent soft switching technology, high-frequency switching power supply technology, and 32-bit DSP full digital SPWM control technology, making the product strong anti-interference ability, fast operation speed, high intelligence, and a powerful functional system, which can meet the needs of users.
  • 【ELECTRICAL ISOLATION】This grid tie inverter complete electrical isolation of machine output and input makes the entire power distribution system well-insulated, and the use of a fully isolated step-up circuit makes its use safer and more reliable.
  • 【SAFE AND SECURE】This grid tie inverter has a great electrical protection function. And the sturdy aluminum alloy shell can better prevent rainwater from eroding the surface, dropping and collision, so you can use it with confidence.This grid tie inverter has passed the professional CE and RoHS certifications.

This grid tie inverter can effectively convert sunlight into clean green energy. It uses imported industrial electronic components, innovative MPPT technology and an isolated high-frequency transformer to make the efficiency higher than 99%, which is a more responsive, and higher output efficiency in photovoltaic power generation application systems.


APPLICATION

  • It is very suitable for grid-connected power generation in schools, power stations and households. It is applicable to 36V solar panel and 36V battery.


DETAILS

  1. Gasket
  2. Round Corners
  3. LED Indicator


SPECIFICATION

  • Model: WVC-1400W
  • Color: Silver
  • Material: Aluminium Alloy
  • Power: 1400W
  • Voltage: 110V
  • Plug Type: US Standard
  • Maximum Input DC Voltage: 54V
  • Peak Power Tracking Voltage: 22-45V
  • Operating Voltage Range: 17-50V
  • Min/Max Start-up Voltage: 22-50V
  • Maximum DC Short Circuit Current: 80A
  • Maximum Input Operating Current: 58A
  • Output Peak Power: 1400watt
  • Rated Output Power: 1350watt
  • Rated Output Current: 12.8A
  • Rated Voltage Range: 80-160VAC
  • Rated Frequency Range: 57-62.5Hz
  • Number of Circuit Connections Per String: 3
  • Static MPPT Efficiency: 99.5%
  • Maximum Output Efficiency: 91.2%
  • Night Time Power Loss:

    SKU: B0D17CGTTH
    Model: RXZER23
    Manufacture: BEYANEE
    Origin: China
