Focal AP 4.380 4-Channel Amplifier, 70 Watts RMS x 4 at 4-Ohms

• Various Amplification Points
• Easy To Use
• Customizable Settings
• Robust Design
• Compact

The AP 4.380 amplifier combines performance and versatility to supply an audio kit by car and thus offer a complete system. Simple to integrate with its RCA input which allows it to be easily connected to the car radio, this reinforcement of class A/B power maximizes sound dynamics by car, for ever deeper listening.

Versatile, the AP 4.380 adapts to a wide range of configurations: 4, 3 or 2 channels, powering numerous loudspeakers. For even more power, its bridgeable function lets you use two channels for a single loudspeaker.

This Class A/B amplifier delivers top-quality performance in its class. It is the ideal complement to Focal Slatefiber, Polyglass, Access, Universal or Auditor loudspeaker kits.

Specifications –
A/B Class Amplifier 4/3/2 channels
CEA power (4Ω) 4x70W RMS
RMS power (2Ω) 4x95W RMS
BTL RMS power (4Ω) 2x190W RMS
Frequency response 10 – 30kHz (3dB)
Total harmonic distortion ≤ 0.06%
SNR (1W/A)>82dB
High-pass crossover 75Hz (CH1/2)
Low-pass crossover 40 – 300Hz (CH3/4)
Bass-boost 0/6/12dB (CH3-4)
Feature Full-range mode
Dimensions (HxLxD) 213 ⁄ 64 x 91 ⁄ 4 x 105 ⁄ 16 (56 x 235 x 262mm)
Net weight 5.3lbs (2.4Kg)
